Hexagon Socket Head Cap Screws

One of Chinese manufacturers of Hexagon Socket Head Cap Screws, offering excellent quality at a competitive price, is DONGSHAO. Feel free to get in touch.

Send Inquiry

Product Description

Hebei Dongshao Fastener Manufacturing Co., Ltd. is a well-known supplier and manufacturer of Hexagon socket head cap screws in China.

The Hexagon socket head cap screws are made of high-quality steel, with high strength, corrosion resistance and other characteristics to ensure product quality;Hexagon socket head cap screws has high dimensional accuracy, precise cutting of hexagonal, stable and reliable use;Suitable for various fields, such as furniture, machinery, automobiles, etc., with wide applicability;Hexagon socket head cap screws are installed with hexagonal wrench, easy to load and unload;The round head is beautiful and simple, suitable for occasions with high appearance requirements;The hexagonal structure allows for better torque transfer to the threads, allowing the screws to be more tightly connected to the parts and not easily loosened.

Product Parameter

(mm)	M3	M4	M5	M6	M8	M10	M12	M16
P	0.5	0.7	0.8	1	1.25	1.5	1.75	2
da max	3.6	4.7	5.7	6.8	9.2	11.2	13.7	17.7
dk max	5.7	7.6	9.5	10.5	14	17.5	21	28
dk min	5.4	7.24	9.14	10.07	13.57	17.07	20.48	27.48
e min	2.303	2.873	3.443	4.583	5.723	6.863	9.149	11.429
k max	1.65	2.2	2.75	3.3	4.4	5.5	6.6	8.8
k min	1.4	1.95	2.5	3	4.1	5.2	6.24	8.44
r min	0.1	0.2	0.2	0.25	0.4	0.4	0.6	0.6
s max	2.08	2.58	3.08	4.095	5.14	6.14	8.175	10.175
s min	2.02	2.52	3.02	4.02	5.02	6.02	8.025	10.025
t min	1.04	1.3	1.56	2.08	2.6	3.12	4.16	5.2
